Key Features And Benefits
The Rosemount 3051 family sets the global standard for pressure measurement, boasting over 10 million installations worldwide. Designed to meet the most demanding industrial challenges, this transmitter offers:
- Unrivaled Precision & Stability: Achieve total confidence in your process control with reference accuracy as high as 0.04% and industry-leading 10-year installed stability. This performance reduces process variability and minimizes maintenance frequency.
- Innovative Coplanar™ Technology: The patented Coplanar design allows for direct mounting to a variety of measurement applications. By eliminating impulse lines, this integrated solution reduces potential leak points by up to 70%, significantly enhancing plant safety and installation efficiency.
- Seamless Integration: Whether your system utilizes 4-20 mA HART®, WirelessHART®, or FOUNDATION™ Fieldbus, the rosemount 3051cd pressure transmitter integrates effortlessly, providing rich diagnostics and actionable insights.
- Safety Certified: With third-party SIL 2/3 certification (IEC 61508), this device is built to protect your personnel and assets, helping you meet stringent safety compliance requirements.
Our Commitment To You
We strictly adhere to the business philosophy of "quality first, reputation paramount, management as the foundation, and service with integrity" . Our mission extends beyond simple supply; we practice the concept of "building quality to foster development" and are dedicated to "pursuing truth and innovation" .
As a partner committed to your success, we strive to enhance your core competitiveness through superior instrumentation and engineering services . We are willing to become your lifelong partner, working hand in hand to achieve shared success and win-win outcomes .
Contact us today to upgrade your operations with the Rosemount 3051.
Product Specifications
|
Parameter |
Specification |
|
Warranty |
Up to 5-year limited warranty |
|
Rangedown |
Up to 150:1 |
|
Communication Protocol |
4-20 MA HART®, WirelessHART®, FOUNDATION™ fieldbus, PROFIBUS® PA, 1-5 V Low Power HART® |
|
Measurement Range |
Up to 2000 psi (137,89 bar) differential Up to 2000 psig (137,89 bar) gage Up to 4000 psia (275,79 bar) absolute |
|
Process Wetted Material |
316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated 316L SST, Gold-plated Alloy 400 |
|
Diagnostics |
Basic Diagnostics, Process Alerts, Loop Integrity Diagnostics, Plugged Impulse Line Diagnostics |
|
Certifications/Approvals |
SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE®, hazardous location, see full specs for complete list of certifications |
|
Wireless Update Rate |
1 sec. to 60 min., user selectable |
|
Power Module Life |
Up to 10-year life, field replaceable (order separately) |
|
Wireless Range |
Internal antenna (225 m) |
